This guide covers the front panel components of the OTC Daihen AVP360 argon arc welding machine. The annotated image shows each part's location. All items listed are genuine OTC Daihen spare parts, with symbols, model numbers, specifications, and quantities for easy identification and ordering.
| Symbol | Part Name | Model / Part Number | Specification | Qty |
|---|---|---|---|---|
| A | DC ammeter | — | 209354-HT/Z DC400A/1mA | 1 |
| R43 | Potentiometer | 4501-042 | RV24YN20SB 100K | 1 |
| R46 | Potentiometer | 4501-042 | RV24YN20SB 100K | 1 |
| R48 | Potentiometer | 4501-042 | RV24YN20SB 100K | 1 |
| R49 | Potentiometer | 4501-042 | RV24YN20SB 100K | 1 |
| R50 | Potentiometer | 4501-042 | RV24YN20SB 100K | 1 |
| R27 | Potentiometer | 4501-039 | RV24YN20SB 5K | 1 |
| R42 | Potentiometer | 4501-039 | RV24YN20SB 5K | 1 |
| — | Potentiometer | 4501-039 | RV24YN20SB 5K | 1 |
| R44 | Potentiometer | 4501-039 | RV24YN20SB 5K | 1 |
| R45 | Potentiometer | 4501-039 | RV24YN20SB 5K | 1 |
| R47 | Potentiometer | 4501-039 | RV24YN20SB 5K | 1 |
| R51 | Potentiometer | 4501-044 | RV24YN20SB 300K | 1 |
| R56 | Potentiometer | 4501-031 | RV24YN20SB 3K | 1 |
| PL1 | Neon indicator light | 4600-342 | N46010A7KR-01 | 1 |
| PL2 | LED light | 4600-332 | DB-40-N-BR | 1 |
| PL3 | LED light | 4600-345 | DB-40-N-BY | 1 |
| PL4 | LED light | 4600-349 | DB-40-N-BG | 1 |
| S1 | Switch | 100-1440 | KCD3B-102 | 1 |
| S3 | Switch | 100-1440 | KCD3B-102 | 1 |
| S4 | Switch | 100-1440 | KCD3B-102 | 1 |
| S6 | Switch | 100-1440 | KCD3B-102 | 1 |
| S7 | Switch | 100-1440 | KCD3B-102 | 1 |
| S2 | Switch | 100-1439 | KCD3B-12 | 1 |
| S5 | Switch | 100-1439 | KCD3B-12 | 1 |
| S8 | Switch | 4250-031 | JW-M21RKK | 1 |
| S9 | Switch | 100-1439 | KCD3B-12 | 1 |
All parts listed above are 100% original OTC Daihen spare parts. Our company is an OTC-designated agent, ensuring you receive authentic components for your welding machine. Whether you need a single replacement or bulk orders, we are here to help.
