OTC DAIHEN CM-6201 Standard MIG/MAG Wire Feeder System
The OTC DAIHEN CM-6201 is a highly reliable standard wire feeder designed for the widely used OTC CPVE welding machine series (CPVE250, CPVE400, CPVE500). Renowned for its durability and consistent performance, this feeder integrates an enclosed spool casing to protect welding wire from factory dust, grinding sparks, and moisture. Its precision printed circuit board and tachometer-controlled motor ensure stable wire feed speed regardless of arc voltage fluctuations, delivering clean weld beads in automotive, container, and mechanical engineering applications.
⚙️ Core Technical Specifications & Drive Roll Matrix
| Drive Roll Model | Wire Ø (mm) |
|---|---|
| U30055M01 | 0.8 / 1.0 |
| U30055M02 (Factory Standard) | 1.0 / 1.2 |
| U30055B07 | 1.2 / 1.6 |
| U30055M03 | 1.2 / 1.2 |
| U30055M04 | 1.4 / 1.4 |
| U30055M05 | 1.2 / 1.4 |
| Specification Parameter | Specification Details |
|---|---|
| Model | CM-6201 |
| Wire Diameters | (0.8)、(1.0)、1.2、(1.4)、(1.6) mm |
| Wire Type | Solid / Flux-Cored Wire |
| Max. Wire Feed Speed | 22 m/min |
| Wire Spool Dimensions | Shaft Ø 50 mm / Outer Ø 300 mm / Width 103 mm |
| Max. Wire Spool Weight | 25 kg |
| Environmental Requirements | Temp: -10~40°C / Humidity: 20~80% (Non-condensing) |
| Dimensions (W×D×H) | 500mm × 214mm × 365mm |
| Weight | 7.1 kg (excluding control cables) |
🔧 Engineering & Operational Guide
- Spool Enclosure Cleanliness: Keep the protective spool cover closed during operation to prevent airborne grinding dust from settling on the welding wire, which otherwise clogs the torch liner.
- Drive Roll Selection: Match the drive roll V-groove size exactly to your wire diameter (e.g., 1.0 mm or 1.2 mm). Mismatched grooves cause wire slipping or premature wire deformation.
- Control Cable Inspection: Check the multi-pin control cable connector at the rear of the feeder regularly for loose pins or oxidation, which can cause erratic wire feed speed control.
